15XB カウンター冷蔵ショーケース

1986年以来、ハイエンド冷蔵庫のリーダー

冷蔵庫のカスタム生産に焦点を当てる

+86-18164468630

E-mail: freezercn@foxmail.com

  • Description

Basic parameters
Type    refrigerated display case Model Model 15XB
Design condition 3(25℃,60%RH) temperature range Temperature range H1(2~8℃)
Energy Efficiency Grade 3 Refrigeration mode Refrigerating system Air cooling Air-Cooling
(mm) Width 2000/2500  custom (L)Depth 1000  custom
(mm) Height 1220  custom (L)Effective Volume -
Cabinet parameters
Cabinet /color Black / White / grey custom External Cabinet material SGCC
Internal Cabinet material SGCC (mm) front end heigth  /
foaming cyclopentane Inside shelf SGCC
Pallets 1 Pallet weight 100KG/m²
Pallet Bearing 100KG/m² Side panel G: 23mm S: 36mm
G: Glass Side Plate Thickness 23 mm S: Foamed Side Plate Thickness 36 mm
Silk Printing Color of Side Plate Glass Silver gray Glass 19mm LOW-E hollow glass
Foot Foundation bolt & Castor wheel Night curtain Deceleration curtain
(kg) Gross weight 90KG/1000mm
Refrigerating system
Compressor Emerson/Panasonic custom temperature Evap Temp ℃ -10℃
Refrigerant R404A (g)Refrigerant charge -
Evaporators Copper Tube with aluminum fins Condenser Copper Tube with aluminum fins
Throttle modes danfoss temperature Temperature control Electronic temperature controller
Defrost Off-Cycle defrost Defrost water treatment Drain pipe
Electric parameter
Condenser Fan motor Crew Depending on unit allocation Evaporating fan EBM
Lighting Canopy & Shelf LED white X-union power(W) Input Power 288W
Plug 16A Plug 220V/50HZ, 380V

【parameter】(Customer requirements can be customized)

Name Model Installation dimensions(L×W×H)mm show(m2) power Voltage/Frequency temperature (℃)

15XB 冷藏展示柜

15XB-2.0M 2000×1000×1220 1.3 650W 220V/50HZ 2~10

15XB 冷藏展示柜

15XB-2.5M 2500×1000×1220 1.9 800W 220V/50HZ 2~10


【photo】





Keywords:15XB カウンター冷蔵ショーケース
